There exists on Docker hub a Docker image called docker. It also has two flavors, "stable" and a "dind" (Docker-in-Docker). What is this image for and what is the purpose of these two different image tags?

Docker, it's important to note, uses a client/server architecture. That is to say, when you run docker on the command line, you're using the Docker client, which connects to a Docker daemon (usually running on localhost port 2376 or 2375, depending on whether TLS is or is not enabled, respectively). Simply put, the stable flavor of the docker image is intended to be used as a Docker client, and the dind flavor is intended to be used as a Docker daemon.

This means that you can run new instances of the Docker daemon and Docker client to create your own isolated Docker workspace. While typically not needed on development machines or even in deployed environments, this can be quite handy for continuous integration (CI) environments where isolation from other build jobs is a must.

Let's briefly explore how these two Docker images work.

First, start up an instance of the docker:dind image:

docker run --privileged -p 12375:2375 -e DOCKER_TLS_CERTDIR="" docker:dind

You'll notice that this image requires the --privileged flag to extend additional privileges to the container. We're also telling Docker (on your computer) to forward localhost port 12375 to port 2375 in the container. Finally, for brevity's sake, we passed -e DOCKER_TLS_CERTDIR= to tell the docker:dind image to start with TLS disabled. (Using TLS is now the recommended and default configuration; more on this below.)

You should see the output of the Docker daemon as it starts, likely ending with something like this:

time="2020-01-30T13:59:33.999230000Z" level=info msg="API listen on [::]:2375"
time="2020-01-30T13:59:33.999501800Z" level=info msg="API listen on /var/run/docker.sock"

Once the container is launched, you can try connecting to your new Docker daemon from the command line on your computer:

DOCKER_HOST=tcp://localhost:12375 docker ps

You should see an empty list of images, since this Docker daemon is isolated from the Docker daemon running on your computer. You could now use this daemon to build Docker images (or do anything else that requires the docker command) in an environment that is isolated from the Docker daemon on your computer.

If you needed to test a different version of the Docker client (and you're on a Mac, see the note below), you could also use the default docker image to connect to your new Docker daemon, like so:

$ docker run -it docker
/ # DOCKER_HOST=tcp://host.docker.internal:12375 docker ps

This starts a new Docker container on your computer, and then inside that container, connects to the port you mapped in the earlier step.

Note: This has been tested successfully only on a Mac; unfortunately it is not currently possible to access the Docker host from within a container like this on Linux. If or when that changes we'll update this post. In the meantime, the docker-compose approach described below should work on all operating systems.

Just for fun, we can also package all of this into a simple docker-compose.yml file that gives the two containers their own network to communicate and even supports TLS by sharing the client certificates to the client container through a volume mount:

version: '3'
    # Starts a Docker daemon at the DNS name "docker"
    # Note:
    #  * This must be called "docker" to line up with the default
    #    TLS certificate name
    #  * DOCKER_TLS_CERTDIR defaults to "/certs
    image: docker:dind
    privileged: yes
      - certs:/certs/client
    # Provides a Docker client container, including the client
    # certs generated by the docker:dind container, above.
    # Notes:
    #  * The name of this container doesn't matter
    #  * The DOCKER_CERT_PATH defaults to /certs/client, the
    #    same path where the docker:dind image generates the
    #    client certificate (and that we've mounted inside this
    #    container).
    # You can execute a shell inside this container by running:
    #   docker-compose exec docker-client sh
    image: docker
    command: sh -c 'while [ 1 ]; do sleep 1000; done'
      DOCKER_HOST: tcp://docker:2376
      - certs:/certs/client

Save this to a file named docker-compose.yml in its own directory, and then run:

docker-compose up

You'll see the Docker daemon start, this time on port 2376 (the port for TLS connections, since we didn't disable it by setting DOCKER_TLS_CERTDIR to an empty value).

In a separate terminal, start a shell in the docker-client container:

docker-compose exec docker-client sh

Now, you should be able to execute commands against your dedicated Docker daemon without manually setting any environment variables, and the communication will be encrypted with TLS.

While some of this may feel like overkill for a development environment, TLS is now the default for the docker:dind image, and it's helpful to become familiar with how this works for troubleshooting CI runners, or any other environment that uses the docker:dind image.

To clean up when you're done testing, you can run docker-compose down to remove any containers started with docker-compose and manually inspect the output of docker ps to find any containers still running that you may wish to stop (via docker stop). Just make sure to run those commands directly on your computer, not within one of the nested Docker client containers.

I hope this tutorial has helped you learn something new about Docker. If you enjoyed this post, you might also want to check out my post on building a production-ready Dockerfile for Django. Thanks for reading, and please comment with any feedback below!
